Zurn Z1201-NL4 EZCarry™ High-Performance Water Closet Carrier / Wall Hung Toilet Carrier – Left-Hand Inlet, Flow to Right, 4" No Hub.
Notes:
-
Water / waste flows to left when seated on water closet.
Product Overview
The Zurn Z1201-NL4 EZCarry™ Water Closet Carrier provides dependable fixture support for commercial and institutional restrooms. Designed with a left-hand inlet and flow directed to the right, this carrier ensures smooth waste propulsion and reduces clogging in low-flow plumbing environments.
The EZCarry™ system is engineered for durability and convenience, supporting up to 500 lbs static load while offering contractors faster installation with pre-assembled components and the optional EZ-SET™ coupling. Compatible with most major water closet manufacturers, it delivers a versatile and sanitary solution for high-traffic restrooms.
Features & Benefits
-
Left-hand inlet, flow directed right for design flexibility
-
Waste propulsion up to 3x farther to reduce clogging in low-flow systems
-
Supports up to 500 lbs static load for reliability in commercial settings
-
Pre-assembled components save contractors time and labor
-
EZ-SET™ coupling option for front-access testing and adjustments
-
Wall-mounted sanitary design for cleaner public restrooms
Specifications
-
Model: Z1201-NL4 EZCarry™
-
System Type: Horizontal siphon jet water closet carrier
-
Main Fitting: Dura-Coated cast iron with 4" no-hub outlet and 2" vent
-
Load Rating: 500 lbs static load
-
Adjustable Features: Gasketed faceplate, universal feet preset at 5-1/2" rough-in, heavy-duty rear anchor tie-down
-
Compliance: ASME A112.6.1M certified
Installation Tips
-
Confirm left-hand inlet orientation before installation.
-
Use universal preset feet for quicker adjustments.
-
Employ the EZ-SET™ coupling for simplified system testing.
-
Anchor securely with top supports and rear tie-downs.
-
Always follow local codes and ASME standards.
FAQs
Q1: What is the inlet orientation of the Z1201-NL4?
It has a left-hand inlet with flow directed to the right.
Q2: Can this carrier fit any commercial toilet?
Yes, it is designed for compatibility with most leading water closet brands.
Q3: What is the maximum supported load?
It supports 500 lbs static load for secure fixture mounting.
Q4: Is the EZ-SET™ coupling included?
The EZ-SET™ coupling is an optional feature, available for easier front-access adjustments.
Q5: Is this carrier lead-free?
Yes, it is constructed of lead-free compliant materials and meets industry safety standards.
