Tekmar 004 Relay 120V (ac) Coil

TekmarSKU: TEK-004

Price:
Sale Price$ 1,646.00 MXN
Stock:
In Stock
Description
Tekmar 004 Relay 120V (ac) Coil

Tekmar 004 Relay 120V (ac) Coil

    Features:

    • Double Pole Double Throw relay (DPDT) to isolate electrical loads

    • Easy to replace ("ice cube" style - no need to remove wiring)

    • LED to indicate when energized

    • Test button for easy test and manual override

    Specifications:

    • Packaged Weight - 0.4lb
    • Dimensions - 3" H x 1-9/16" W x 2-3/8" D
    • Approvals - CSA C US
    • Power Supply (Coil) - 24V (ac) +10%, -20%, 50Hz 2.7VA, 60Hz 2.3VA
    • Relay Contacts (Max) - 10 A Resistive at 250V (ac) N.O. ,N.C. - 10 A Resistive at 30V (dc) N.O., N.C. - 7 A Inductive at 250V (ac)
    • Relay Contacts (Min) - 10mA 1V (dc)
    • Ambient Conditions - -40 to 140 Degree F (-40 to 60 Degree C), RH <85% Non-Condensing
    • Warranty - Limited 3 Year Warranty

    Installation Manual
