Description
BMI 31548 1/2"PEX - COMPACT - Straight Stop - Chrome Plated Valve - Hammer Arrester - 1/4 Turn - Lead Free (Package Quantities)
Features & Benefits:
- Forged brass & copper with total chrome plated
- Quarter turn open & shut
- Self-lubricating P.T.F.E. seats
- Double O-ring for more safety
- Piston type (permanently sealed chamber) arrester
- Copper body chamber with brass cap & brass piston, AA size
- Maximum temperature: 212 °F (100 °C)
- Maximum pressure: 250 psi (17.5 kgf/cm 2 )
- Absorptive capacity: 150 psi (10.5 kgf/cm 2 )
Compliance:
-
Certified By:
- IAPMO (cUPC)
-
Complies With:
- ASME A112.18.1
- CSA B125.1-11
- F1807
- F1960
- ANSI/NSF 61
- ANSI/NSF 372
- ANSI/NSF 14 PDI WH201
- ASSE 1010
Technical Downloads:
- BMI Lead Free Chrome Supply Valves W/ Hammer Arrester: Specification Submital
- BMI Lead Free Chrome Supply Valves: W/ Hammer Arrester: Promotional Flyer
