Description
BMI 09619 1/2"C x 3/8"OD Angle Stop - Chrome Plated Valve - 1/4 Turn - Lead Free
Features & Benefits:
- Forged brass with chrome plated body
- Quarter turn open & shut
- Self-lubricating P.T.F.E. seats
- Double O-ring for more safety
- Suitable for both plumbing and hydronic heating application
List of Materials:
- Body: C46500
- Bonnet: C46500
- Ball: C46500
- Seat: PTFE
- Stem: C46500
- O-Ring: EPDM
- Handle: ABS
- Screw: SS304
- Comp.Ring: H65 Brass
- Nut: C37700
Compliance:
-
Certified By: IAPMO
-
Complies With:
- ASME A112.18.1
- CSA B125.1-11
- F1807, F1960
- ANSI/NSF 61
- ANSI/NSF 372
- ANSI/NSF 14
Technical Downloads:
- BMI Lead Free Chrome Supply Valves: Specification Submital
- BMI Lead Free Chrome Supply Valves: Promotional Flyer
